Portable PA system equipped with a 100 W power amp, coaxial compression driver with 1.4” voice coil HF and 6.5” cone LF, and a 3-channel mixer.

Expand your range. Extend your reach

The STAGEPAS 100 portable PA system strikes a perfect balance between high-quality sound and ultimate portability, allowing you to turn virtually any location into your own intimate live stage. Available in two versions, one with a battery and one without, the lightweight yet durable design, easy operation, and impressive sound of the STAGEPAS 100 will help you connect with your audience and fully express your performance.

The battery-equipped STAGEPAS 100BTR mkII also provides audio I/O via USB or Bluetooth®, letting you deliver crystal-clear sound to remote audiences or communicate seamlessly with colleagues anywhere.

Compact design. Big sound.

Far more than just a speaker, the STAGEPAS 100 delivers impressive sonic performance by leveraging some of the same technologies used in our high-end professional products. A powerful, high-quality coaxial compression driver combined with proprietary FIR-X filters for the HF and LF crossover deliver sound pressure, precise phase response, and a natural dispersion to ensure every nuance of your performance is conveyed loud and clear to your audience.

Start the show in seconds

With effortless setup and intuitive operation, the STAGEPAS 100 will have you sounding great in no time. Power on, plug in your mic and instrument, raise the volume, and you’re ready. The master EQ is right on the front panel, making it easy to dial in your sound or adjust settings on the fly.

A PA in the palm of your hand

With all the essentials for a compact PA packed into a durable cabinet weighing just 11 pounds, the STAGEPAS 100 takes portability to a whole new level. It's like having a personal stage you can easily carry in one hand and set up anywhere, anytime.

Support hybrid application

The battery-equipped STAGEPAS 100BTR mkII offers audio I/O functionality via a USB or Bluetooth connection, allowing voice signals to be sent and received to and from a computer or smartphone. It can also be used for hybrid applications such as streaming of live performances or online seminars via mobile devices connected to a network.

What's in the box:

• Yamaha STAGEPAS 100 2-Way 6.5" 100W Portable PA System with Bluetooth

• Power Cord

• Power Adapter

Features at a glance:

• 100 W Class-D amplifier

• 1.4” HF + 6.5” LF high-quality coaxial compression driver using an FIR filter for the crossover

• 3-channel mixer (2 monaural mic/line + 1 line)

• Equipped with a 2-band master EQ

• Compatible with Hi-Z input (Channel 2 only)

• Equipped with mix-out

• Carrying handle doubles as an adjustable stand

• Compatible with audio accompaniment over Bluetooth

• Optional carrying bag (BAG-STP100) available for convenient transport

Specifications:

Speaker Configuration	1x 2-Way Loudspeaker
Number of Input Channels	3 (2 x Mono, 1 x Stereo)
Amplifier Power Rating	HF: 1x 7 W LF: 1x 93 W Total: 60 W RMS 100 W Peak
HF Driver	1x 1" / 2.5 cm Compression Driver
LF Driver	1x 6.5" / 16.5 cm Woofer
Audio I/O	1x Combo XLR-1/4" 3-Pin Female Balanced/Unbalanced Mic/Line Input 1x Combo XLR-1/4" 3-Pin Female Balanced/Unbalanced Mic/Line/Hi-Z Input 1x 1/8" / 3.5 mm TRS Female Aux Input 1x XLR 3-Pin Male Line Output
USB I/O	No
Bluetooth	Bluetooth 5.0
