Description
Versatile and feature-rich digital wireless system for those who sing, speak or play instruments that allows for seamless product pairing and management via the EW-D Smart Assist App. Receive state-of-the-art live sound.
Features at a Glance:
- Digital transmission operating in the UHF spectrum greatly enhances range, reliability and scalability
- Smart Assist App connects via Bluetooth Low Energy for a streamlined setup and operation at a distance
- Auto scan creates reliable connections with minimal time and effor
- 134 dB audio input dynamic range eliminates need for sensitivity adjustments and preserves every detail
- Elimination of intermodulation enables channels to be placed in an equidistant tuning grid 600 kHz apart
- 56 MHz of tuning bandwidth and equidistant spacing enables up to 90 channels
- 2,240 selectable frequencies allow for fine tuning
- Lithium-Ion battery pack (sold separately) delivers up to 12 hours of operation (up to 8 hours of operation with 2x provided AA batteries)
Specifications:
| Frequency range | 606.2 - 662 MHz |
| THD | ≤ -60 dB for 1 kHz @ -3 dBfs input level |
| Weight | approx. 1000 g (without antennas and power supply) |
| Operating temperature | -10 °C - +55 °C (14 °F - 131 °F) |
| Operating relative humidity | 5 - 95 % (non-condensing) |
| Audio frequency response | 20 Hz - 20 kHz (-3 dB) @ 3 dBfs |
| Input voltage range | 11 - 13 V |
| Current consumption | < 300 mA |
| Power supply | 2 AA batteries 1.5 V (alkaline manganese) or BA 70 rechargeable battery pack |
| Transmission power | BLE: max. 10 mW EIRP |
| Dimensions | 212 x 44 x 189 mm |
| Audio output level | 18 dBu max. |
