Roasted Maple Neck With Bound Rosewood Fingerboard And Block Inlays
The Surfliner Deluxe elevates the Surfliner platform with all new appointments. Introducing Guild’s first-ever roasted maple neck, for a dark aged appearance with added stiffness and stability. A bound rosewood fingerboard with block inlays compliments the satin finished C-shaped 25.5” scale neck providing a smooth playing experience.
New Guild Floating Vibrato Tailpiece (Gfvt)
Developed for the Surfliner Deluxe – the new Guild Floating Vibrato Tailpiece (GFVT) opens the Surfliner platform to new playing styles, capable of a broad range of vibrato effects, from subtle flutters to deep swells. The GFVT is equipped with a nylon insert and easily accessible tension screw for ultimate control of bar tension. Featuring an embossed “G” for classic Guild DNA.
Hss Pickup Configuration Featuring Dearmond Aerosonic Single Coil And Guild Hb-2 Humbucker Pickups
Outfitted with a bridge HB-2 Humbucker with Alnico II magnets, the HB-2 was developed to recreate the rich, warm tone of vintage Guild humbuckers in a standard size format. The HB-2 is paired perfectly with the chiming single-coil tones of the two DeArmond Aerosonic middle and neck pickups.
The Surfliner Deluxe debuts a classic 5-way blade switch. This instantly recognizable pickup switching offers quick access from rhythm to solo tones at the flick of a switch.
Solid Poplar Body With Vintage-Inspired Offset Appeal
Built with a lightweight Poplar solid body, the new Surfliner Deluxe features a gloss finish and matching headstock, available in Evergreen Metallic, Rose Quartz Metallic and Black Metallic.
Features at a Glance:
- Lightweight poplar body in an exceptionally comfortable offset-style design
- Maple neck in a highly versatile “C” shape
- Rosewood fingerboard featuring elegant binding and block inlays
- Narrow jumbo frets in a 10-inch radius are sure to please guitarists of all styles and backgrounds
- Versatile HSS pickup configuration that covers everything from traditional surf sounds to hard rock to blues and beyond
- Tune-o-matic bridge with Guild Vibrato system captures the gliding vibrato sounds of both the surf guitar and shoegaze era
Specifications:
| Body Type | Solid Body |
| Body Shape | Guild Surfliner |
| Body Top | N / A (Solid Body) |
| Body Wood (Solid Bodies) | Poplar |
| Neck Material | Roasted Maple |
| Scale Length | 25 1/2" (648mm) |
| Neck Shape | C Shape |
| Nut Width | 1 11/16" (43mm) |
| Neck Thickness | 1st Fret 21mm |
| Neck Thickness | 9th Fret 23.5mm |
| Truss Rod | Dual Action |
| Truss Rod Wrench | 4mm Allen Key |
| Fingerboard Material | Indian Rosewood |
| Fingerboard Radius | 10" (254mm) |
| Fingerboard Inlays | Blocks - Pearloid |
| Frets Total | 23 |
| Fret Type | Narrow Jumbo |
| Color | Rose Quartz (RSQ) |
| Bridge String Spacing | 2" (50mm) |
| Hardware Finish / Plating | Nickel |
| Bridge | Tune-O-Matic |
| Tailpiece | Guild Floating Vibrato |
| Nut Material | Composite |
| Tuning Machines | Guild Modern Style Closed-Gear Locking |
| Strap Buttons | Vintage Style - Large |
| Pickguard | Surfliner Deluxe HSS 3-Ply Pearloid/Black/White |
| Bridge Pickup | Guild HB-2 Humbucker Nickel - Bridge |
| Neck Pickup | DeArmond Aerosonic Single Coil Pickup Neck Nickel/Black |
| Pickup Switch | 5-Way Blade:
1. Bridge Pickup -
2. Bridge and Middle Pickups -
3. Middle Pickup -
4. Middle and Neck Pickups -
5. Neck Pickup |
| Controls | Master Volume and Tone and 5-Way Blade Pickup Switch |
| Strings | D'Addario EXL110 - Nickel Wound Regular Light (.010" - .046") |
| Included Case | Case Sold Separately |
Upper Bout Width
Lower Bout Width | 11" (280mm)
13 5/8" (346mm) |
Body Depth Upper Bout
Body Depth Lower Bout | 1 1/2" (38mm)
1 1/2" (38mm) |
Body Length
Overall Length | 18" (457mm)
41" (1041mm) |
